This item is no longer available.12.9MW Kawasaki HFO/LNG Gas Turbine Plant- 2018 Unused (Complete Plant)
Welcome to Salvex Marketplace where you can buy surplus, salvage, and discounted gas turbines and generators as part of a commercial repurposing strategy.
Attention
This item is no longer available.12.9MW Kawasaki HFO/LNG Gas Turbine Plant- 2018 Unused (Complete Plant) Share with Buyers
-
-
Welcome to Salvex Marketplace where you can buy surplus, salvage, and discounted gas turbines and generators as part of a commercial repurposing strategy.
| ID | : | 183009531 |
| Seller | : | |
| Seller Industry | : | |
| Original Wholesale Value | : | $15,000,000 |
| Quantity | : | 1 Units |
| Manufacturer | : | |
| Condition | : | This is an unused plant that was for a cancelled project in 2018. The plant is currently dismantled and sealed in a warehouse. The plant is sold as is, where is and if needed, logistics could be arranged. Buyer is responsible for loading, freight and logistics to final destination. |
| | : | |
| Product Location | : | |
| End Time | : | |
| Loading Cost | The location does not have loading capabilities and plant is already dismantled, never installed .This plant is ready to deliver, crated and well kept in the owners warehouse. |
Item Description
This 12.9MW Kawasaki HFO/LNG Gas Turbine Plant- 2018 Unused (Complete Plant) is no longer needed for the company's own operation and is being sold as an asset liquidation for its owner. The Plant equipment consists of Gas Turbines, Generators, Transformers, Boilers, Switch/Control panels, and Auxiliary equipment.
The plant is 12MW in total, the plant has 3 gas turbines with 4MW capacity in each (5000kVa). This is a Japanese 2018 brand-new, unused plant from a canceled project. The plant has gone through all the required installation maintenance (i.e. preventive maintenance etc.) This plant can run on natural gas/city gas.
Gas Turbine: Kawasaki Heavy Industries, Ltd (3 Units)
- Model M1T-26
- Rated output 4347 KW 40 ° C
- Rotational speed 22000/1500 min-1
- Month of production 2018-2
- Kawasaki Heavy Industries, Ltd.
Hitachi Decelerator
- Model MPG160-23
- Reduction ratio 14.618
- Transmission power 4800KW
- Output rotational speed 1500 min-1
- construction number 0A006846A
- Manufacturing date 2018/2
- T5000A-BER
- Rated output 4000kW
- Voltage 6600v
- Frequency 50Hz
- gas turbine MIT-26
- Generator TAKL-SCKE
- Manufacturing date 2018-3
- Current 438A
- Number of phases 3 φ
- Height 3800 × width 3500 × depth 8500
- Simple release cycle 1 axis type
- Construction Consists of a centrifugal two-stage compressor, an axial flow four-stage turbine, a single-tube can combustor and a reduction gear
- Output 4,347kw(40?)
- Rotational speed/Turbine main shaft- 22,000min?1
- Output axis-1,500min?1
- Reduction gear-Planetary + Parallel gear reducer
- Starter motor-Electric type
- Fuel controller- Electric type A heavy oil No. 1 (JIS K 2205)
- Fuel used Oil type: Synthetic base oil (AERO SHELL ASTO-500)
- Used lubricating oil Oil amount: 240L
Fuel property limit conditions
- It is usually available if you want a representative of A heavy oil to the supplier you plan to purchase.
- Dynamic viscosity (50 ° C): 2.0 to 2.8 mm2 / s
- Sulfur content: 0.5% wt or less
- 10% residual oil residual carbon content: 0.55% wt or less
- Density (15 ° C): 865 kg / mm3 or less
- Phase number 3
- Number of poles 4
- Voltage 6600V
- Power factor 0.8
- Rated continuous
- Phase number 3
- Number of poles 4
- Voltage 6600V
- Power factor 0.8
- Rated continuous
- Output 5000KVA
- Current 438A
- Field voltage 70V
- Annual operation time 1000 hours
- Rotation speed 1500 min-1
- Frequency 50Hz
- Field current 455A
- Output 5000KVA
- Current 438A
- Field voltage 70V
- Annual operation time 1000 hours
- Rotation speed 1500 min-1
- Frequency 50Hz
- Field current 455A
- Refrigerant temperature 40 ° C
- Field winding 155 (F)
- Heat resistant class; Armature winding 155 (F)
- AC exciter: Output 39 KVA
- Voltage 55V
- Current 410A
- Field voltage 90V
- Protection method IP20
- Cooling method ICO 1
- Mass 9660 Kg
- Standard JEC-2130-2016
- The main points of the alternator are as follows.
- Format Protective type, free air flow type (IP22)
- Construction- Horizontal axis type, rotating field type
- Rated capacity-5000kv
- Rated output-4000kw
- Rated voltage 6,600V
- Rated current- 437A(reference)
- Rated power factor-0.8(delay)
- Rated Continuous Frequency -50Hz
3. Transformer( Make Fuaji Electronics)
Load tap switching transformer (2 Units) • Phase number 3 • Rated frequency 50Hz • Cooling method ONAN / ONAF • Rated Capacity (KVA) Primary 20000/22000 Secondary 20000/22000 • Rated voltage (V) primary 66000 secondary 6600 • Rated current (A) primary 175/192 secondary 1750/1925 • Test voltage value (KV) primary L1 350 AC 140 secondary L1 60 AC22 • Temperature rise limit • Number of turns 65K Oil 60K • 23T each in weight
